Aluminium Plates
5083, 6061 & 7075 grade aluminium plates for aerospace, marine shipbuilding and structural fabrication.
Product Overview
Aluminium plate is fabricated into marine hull panels, structural tanks and aerospace components where weight saving drives the design — a third the density of steel with respectable strength depending on grade.
We hold marine-grade 5083, structural 6061-T6 and the high-strength aerospace grade 7075.
Aluminium Plates — In Our Stockyard
Available Grades
| Grade | Standard | Description |
|---|---|---|
| 5083-H111 | ASTM B209 | Marine shipbuilding — excellent seawater resistance |
| 6061-T6 | ASTM B209 | Structural & general fabrication |
| 7075-T6 | ASTM B209 | High-strength aerospace structural plate |
Specifications
- Thickness3mm – 60mm
- Width1500 – 2500mm
- Length3000 – 6000mm
- ManufactureHot Rolled, Plate Mill
- TestingDimensional, UT on request
- CertificationEN 10204 3.1 Mill Test Cert.
- ConditionAs Rolled / Heat Treated
- PackingBundled with edge protection
Technical Note — 5083 is supplied in the H111 temper for its resistance to exfoliation corrosion in sustained marine exposure, while 7075-T6's higher strength comes with lower weldability — best suited to mechanically fastened aerospace assemblies.
Applications
Aerospace Structures
Marine Shipbuilding
Structural Fabrication
Tank Manufacturing
