Titanium Sheets
Home Products Titanium Sheets
Lightweight High-Strength Sheet

Titanium Sheets

Grade 1, 2 & 5 titanium sheets for aerospace skins, marine fabrication and chemical processing equipment.

Titanium Sheets
ASTM / ASME Certified Material

Product Overview

Titanium sheet is formed into aerospace skins, marine components and chemical processing equipment where its weight saving and corrosion resistance justify the premium over stainless steel.

We stock Grade 1 for the most formable applications, Grade 2 as the general commercially pure standard, and Grade 5 (Ti-6Al-4V) for structural aerospace fabrication.

Thickness0.5mm – 6mm
Width1000 / 1219mm
FinishCold Rolled, Annealed & Pickled
GradesGrade 1, Grade 2, Grade 5
Request Quote Talk to Our Team
Photo Gallery

Titanium Sheets — In Our Stockyard

Specification

Available Grades

GradeStandardDescription
Grade 1 (UNS R50250)ASTM B265Most formable — cold-forming applications
Grade 2 (UNS R50400)ASTM B265General commercially pure corrosion-resistant sheet
Grade 5 / Ti-6Al-4V (UNS R56400)ASTM B265High-strength aerospace structural sheet
Technical Data

Specifications

  • Thickness0.5mm – 6mm
  • Width1000 – 1219mm
  • Length2000 – 3000mm (sheet cut)
  • ManufactureCold Rolled
  • FinishAnnealed & Pickled
  • TestingPMI, Surface, Dimensional
  • CertificationEN 10204 3.1 Mill Test Cert.
  • PackingPVC-coated, edge-protected bundles

Technical Note — Sheet surfaces are protected with a peelable film during transit to prevent scratching, since titanium's thin oxide layer — while chemically protective — is easily marked by abrasive handling before fabrication.

Where It's Used

Applications

Aerospace Skins & Panels

Medical Equipment

Marine

Chemical Processing

Get a Price

Request a Quote for Titanium Sheets

Share size, grade and quantity for the fastest response from our sales team.
