Duplex & Super Duplex Sheets

High-Strength Duplex Sheet

Duplex & Super Duplex Sheets

Duplex 2205 & Super Duplex 2507 sheets for offshore platform fabrication, chemical tanks and desalination equipment.

Duplex & Super Duplex Sheets

ASTM / ASME Certified Material

Product Overview

Duplex and super duplex sheet is fabricated into tank linings, offshore module cladding and marine equipment where standard stainless would risk chloride stress-corrosion cracking.

Both 2205 and 2507 are held in cold rolled, solution-annealed condition, ready for cutting and forming.

Thickness0.5mm – 6mm
Width1000 / 1219 / 1500mm
FinishCold Rolled, Annealed & Pickled
Grades2205, 2507

Request Quote Talk to Our Team

Photo Gallery

Duplex & Super Duplex Sheets — In Our Stockyard

Specification

Available Grades

Grade	Standard	Description
Duplex 2205 (UNS S31803 / S32205)	ASTM A240	Offshore fabrication & chemical tank linings
Super Duplex 2507 (UNS S32750)	ASTM A240	Subsea & extreme-pitting-resistance fabrication

Technical Data

Specifications

Thickness0.5mm – 6mm
Width1000 – 1500mm
Length2000 – 3000mm (sheet cut)
ManufactureCold Rolled

Finish2B, Annealed & Pickled
TestingFerrite Content, Surface, Dimensional
CertificationEN 10204 3.1 Mill Test Cert.
PackingPVC-coated, edge-protected bundles

Technical Note — Ferrite balance is confirmed on every coil before dispatch, since a skewed austenite/ferrite ratio reduces both the strength and the corrosion-resistance advantage the material is specified for.

Where It's Used

Applications

Offshore Platforms

Chemical Tanks

Desalination

Marine Fabrication

Get a Price

Request a Quote for Duplex & Super Duplex Sheets

Share size, grade and quantity for the fastest response from our sales team.
