Tool & Alloy Steel Bars

Die, Mould & Bearing Grade Bar

Tool & Alloy Steel Bars

D2, H13, O1 & EN31 tool and bearing steel bars for die making, hot-work tooling and precision bearing components.

Tool & Alloy Steel Bars

ASTM / ASME Certified Material

Product Overview

Our tool and alloy steel bar range serves die makers, mould manufacturers and bearing component producers with grades selected for wear resistance, toughness or dimensional stability depending on the tooling application.

D2 and O1 cover cold-work die and gauge applications, H13 serves hot-work forging and die-casting dies, and EN31 (52100-equivalent) is the standard for precision bearing races and rollers.

Diameter6mm – 250mm
LengthUp to 3m
FinishAnnealed, Ground, Peeled
CertificationEN 10204 3.1 Mill Test Cert.

Request Quote Talk to Our Team

Photo Gallery

Tool & Alloy Steel Bars — In Our Stockyard

Specification

Available Grades

Grade	Standard	Typical Service
D2 (AISI D2)	ASTM A681	High-carbon, high-chromium cold-work die steel
H13 (AISI H13)	ASTM A681	Chromium hot-work steel for forging & die-casting dies
O1 (AISI O1)	ASTM A681	Oil-hardening cold-work steel for gauges & punches
EN31 (AISI 52100 equiv.)	IS 1570	Bearing-grade steel for races & rollers

Technical Data

Specifications

Diameter6mm – 250mm
Length1m – 3m
ManufactureHot Rolled, Forged, Ground
ConditionSoft Annealed

TestingHardness, Dimensional, UT on request
CertificationEN 10204 3.1 Mill Test Cert.
PackingBundled, tagged by heat number
GradesD2, H13, O1, EN31

Technical Note — Bar is supplied soft-annealed with a documented hardness band suited to machining before heat treatment; on request we can pre-select stock closest to your target grain-flow orientation for large die blocks.

Where It's Used

Applications

Die & Mould Making

Bearing Components

Press Tooling

Forging Dies

Get a Price

Request a Quote for Tool & Alloy Steel Bars

Share size, grade and quantity for the fastest response from our sales team.
